white smoke after aos replacement

[JFP in PA]

A quick look seems to confirm what you are finding. We bought ours several years ago from a local lab supply house that was later acquired by a larger firm, and a search seem to show they have gone now to all digital inches of water measurement equipment, starting at around $100. Someone out there must still make the old style mechanical gauge...........

[JFP in PA]

OK, found something similar on Amazon, higher range, but still workable: http://www.amazon.com/dp/B002E81ZC8/ref=biss_dp_t_asn So they do still exist.........

[Ahsai]

This one looks pretty good too http://www.amazon.com/Winters-Pressure-Internals-Display-Accuracy/dp/B0087V09H8

You can also get a digitlal one at a higher price http://www.amazon.com/Meters-PDMM01-Digital-Manometer-Measure/dp/B005FU5HFI/ref=sr_1_1?s=industrial&ie=UTF8&qid=1389551297&sr=1-1&keywords=Manometer

This digital one is only $48 but with only one review http://www.amazon.com/Large-Digital-Manometer-Pressure-Meter/dp/B00B3PUIOO/ref=sr_1_10?ie=UTF8&qid=1389575957&sr=8-10&keywords=Manometer

Edited January 13, 2014 by Ahsai

[Mijostyn]

OK, found something similar on Amazon, higher range, but still workable: http://www.amazon.com/dp/B002E81ZC8/ref=biss_dp_t_asn So they do still exist.........

This one looks pretty good too http://www.amazon.com/Winters-Pressure-Internals-Display-Accuracy/dp/B0087V09H8

You can also get a digitlal one at a higher price http://www.amazon.com/Meters-PDMM01-Digital-Manometer-Measure/dp/B005FU5HFI/ref=sr_1_1?s=industrial&ie=UTF8&qid=1389551297&sr=1-1&keywords=Manometer

This digital one is only $48 but with only one review http://www.amazon.com/Large-Digital-Manometer-Pressure-Meter/dp/B00B3PUIOO/ref=sr_1_10?ie=UTF8&qid=1389575957&sr=8-10&keywords=Manometer

OK guys, this is TTTTOO cool. I got the WIKA gauge JFP found. It has a standard threaded fitting on the back for NPT compressor stuff. It looks very heavy duty and is quite heavy. If you look at 6 olck just above the WIKA label you will see a calibration screw. Very cool. The new Oil cap is coming. I do believe I can drill and thread right into the top of the cap and mount the gauge directly with epoxy support. Better yet I think it will actually fit under the hood! I can keep it on all the time if the heat does not get to it.

I will take pictures when the job is done.

Edited January 17, 2014 by Mijostyn

[JFP in PA]

OK, found something similar on Amazon, higher range, but still workable: http://www.amazon.com/dp/B002E81ZC8/ref=biss_dp_t_asn So they do still exist.........

This one looks pretty good too http://www.amazon.com/Winters-Pressure-Internals-Display-Accuracy/dp/B0087V09H8

You can also get a digitlal one at a higher price http://www.amazon.com/Meters-PDMM01-Digital-Manometer-Measure/dp/B005FU5HFI/ref=sr_1_1?s=industrial&ie=UTF8&qid=1389551297&sr=1-1&keywords=Manometer

This digital one is only $48 but with only one review http://www.amazon.com/Large-Digital-Manometer-Pressure-Meter/dp/B00B3PUIOO/ref=sr_1_10?ie=UTF8&qid=1389575957&sr=8-10&keywords=Manometer

OK guys, this is TTTTOO cool. I got the WIKA gauge JFP found. It has a standard threaded fitting on the back for NPT compressor stuff. It looks very heavy duty and is quite heavy. If you look at 6 olck just above the WIKA label you will see a calibration screw. Very cool. The new Oil cap is coming. I do believe I can drill and thread right into the top of the cap and mount the gauge directly with epoxy support. Better yet I think it will actually fit under the hood! I can keep it on all the time if the heat does not get to it.

I will take pictures when the job is done.

Ours are mounted to the oil cap and only used as a diagnostic's tool, so they don't remain in the car.

[Mijostyn]

OK, found something similar on Amazon, higher range, but still workable: http://www.amazon.com/dp/B002E81ZC8/ref=biss_dp_t_asn So they do still exist.........

This one looks pretty good too http://www.amazon.com/Winters-Pressure-Internals-Display-Accuracy/dp/B0087V09H8

You can also get a digitlal one at a higher price http://www.amazon.com/Meters-PDMM01-Digital-Manometer-Measure/dp/B005FU5HFI/ref=sr_1_1?s=industrial&ie=UTF8&qid=1389551297&sr=1-1&keywords=Manometer

This digital one is only $48 but with only one review http://www.amazon.com/Large-Digital-Manometer-Pressure-Meter/dp/B00B3PUIOO/ref=sr_1_10?ie=UTF8&qid=1389575957&sr=8-10&keywords=Manometer

OK guys, this is TTTTOO cool. I got the WIKA gauge JFP found. It has a standard threaded fitting on the back for NPT compressor stuff. It looks very heavy duty and is quite heavy. If you look at 6 olck just above the WIKA label you will see a calibration screw. Very cool. The new Oil cap is coming. I do believe I can drill and thread right into the top of the cap and mount the gauge directly with epoxy support. Better yet I think it will actually fit under the hood! I can keep it on all the time if the heat does not get to it.

I will take pictures when the job is done.

Ours are mounted to the oil cap and only used as a diagnostic's tool, so they don't remain in the car.

If it fits under the hood and is durable enough to tolerate the environment it might be handy to have on board if something happens. You need to use it on multiple cars. It probably won't clear the fan anyway. But, it is a really nice gauge. Thanx!!

[bilba]

hello

AOS Was changed twice ( this year ) still smoke coming out from the exhaust ( sometimes left sometimes right and both.
Also still the presence of the amount of oil inside the plenum and throttle body

The most important question

What's the reason for the oil get into plenum/throttle if i've changed AOS twice since last DECEMBER !!

vents and hoses all are ok

[JFP in PA]

hello

AOS Was changed twice ( this year ) still smoke coming out from the exhaust ( sometimes left sometimes right and both.

Also still the presence of the amount of oil inside the plenum and throttle body

The most important question

What's the reason for the oil get into plenum/throttle if i've changed AOS twice since last DECEMBER !!

vents and hoses all are ok

Very simple: When the AOS fails, it tends to pull a lot of oil into the intake system. There are a myriad of little nooks and crannies where the oil can sit in the intake, so it comes out very slowly over time causing prolonged smoke unless you pull the entire intake off and manually clean it out.

[bilba]

hello

AOS Was changed twice ( this year ) still smoke coming out from the exhaust ( sometimes left sometimes right and both.

Also still the presence of the amount of oil inside the plenum and throttle body

The most important question

What's the reason for the oil get into plenum/throttle if i've changed AOS twice since last DECEMBER !!

vents and hoses all are ok

Very simple: When the AOS fails, it tends to pull a lot of oil into the intake system. There are a myriad of little nooks and crannies where the oil can sit in the intake, so it comes out very slowly over time causing prolonged smoke unless you pull the entire intake off and manually clean it out.

thanks for your reply

throttle and plenum has been cleaned twice

the problem is The oil in TB/PLNUM bcoz of oil coming from vent line and drops in the intake

What is the reason for this amount of oil seep out from AOS Through vent line Which cause the oil in TB/intake

As I mentioned above to aos Was changed 2 time

Is because of bad ring ?

Edited March 15, 2014 by bilba

[JFP in PA]

hello

AOS Was changed twice ( this year ) still smoke coming out from the exhaust ( sometimes left sometimes right and both.

Also still the presence of the amount of oil inside the plenum and throttle body

The most important question

What's the reason for the oil get into plenum/throttle if i've changed AOS twice since last DECEMBER !!

vents and hoses all are ok

Very simple: When the AOS fails, it tends to pull a lot of oil into the intake system. There are a myriad of little nooks and crannies where the oil can sit in the intake, so it comes out very slowly over time causing prolonged smoke unless you pull the entire intake off and manually clean it out.

thanks for your reply

throttle and plenum has been cleaned twice

the problem is The oil in TB/PLNUM bcoz of oil coming from vent line and drops in the intake

What is the reason for this amount of oil seep out from AOS Through vent line Which cause the oil in TB/intake

As I mentioned above to aos Was changed 2 time

Is because of bad ring ?

Unfortunately, most of the oil from the AOS is inside the intake runners them selves, not just the area behind the throttle body. To get it all out, you literally need to remove the entire intake system and clean it manually. If left alone, it will burn off over time, but how much time depends upon how much oil is in there.

If they changed the vent line when they did the AOS, there should be no oil in it. If it is a new vent line, and it has oil in it, I would suggest getting a leak down test run on the engine to make sure it is sealing tightly.

[bilba]

we didnt change any vent line just the AOS

i will wait some days and see

thanks JFP

[JFP in PA]

we didnt change any vent line just the AOS

i will wait some days and see

thanks JFP

When you get an AOS going south, you really should change everything connected to it as there will be built up oil residue in them. People often skip this to save money, but it is false economy because you usually end up going back and changing it later.
