Water Pump Replacement

Loren
 Share

Recommended Posts

  • 2 weeks later...
  • Replies 66
  • Created
  • Last Reply

Top Posters In This Topic

Popular Days

Top Posters In This Topic

Popular Days

Popular Posts

JeTexas
JeTexas

Here's the video. Sorry for the shakiness and poor audio. I found my old 24-bit PCI soundcard isn't supported in Windows 7, and I've yet to invest in a new USB recording system. I only make these wh

Loren
Loren

Water Pump Replacement See Robin's DIY at his site: 996 Water pump replacement/ Alternate PDF file (if link does not work) 996_water_pump_replacement_procedure.pdf 996_water_pump

SparkyRacer
SparkyRacer

I just finished doing this myself, had the same problem and thought I'd clarify a couple of points for future readers. The pump comes out the bottom. I had the car up on jack stands with a jack supp

Posted Images

  • 8 months later...
mclakers Member

mclakers

Posted
Posted

loren, i need your help!!!

i followed all the diy instruction on removing the water pump. i got all the screws off the water pump, but my problem is that it wont come out, i tried taking it out trough the top and theres not enough clearance, and i tried the bottom and its the same problem. Do you know if the water pump comes out the top or the bottom? and if theres any specific angle or something else i can do to take out the pump? thanks in advance.

03 carrera cab, 6 spd

mclakers Member

mclakers

Posted
Posted (edited)

yes. I loosend the bracket, if try to take it out from the top it hits the bracket and the same happens in the bottom, but in the bottom it also hits a small water hose that's made out of metal . Could it be that I have the car on jack stands intead of the ground? Or should I completely remove the bolts from the bracket

I finally took it out. Had to loosen a few other hoses but finally got thanks

Edited by mclakers
  • 2 months later...
SparkyRacer Member

SparkyRacer

Posted
Posted
yes. I loosend the bracket, if try to take it out from the top it hits the bracket and the same happens in the bottom, but in the bottom it also hits a small water hose that's made out of metal . Could it be that I have the car on jack stands intead of the ground? Or should I completely remove the bolts from the bracket

I finally took it out. Had to loosen a few other hoses but finally got thanks

I just finished doing this myself, had the same problem and thought I'd clarify a couple of points for future readers. The pump comes out the bottom. I had the car up on jack stands with a jack supporting the engine. I completely removed the two bolts from the rear engine support but left the two nuts just barely on. You could probably completely remove the nuts too, it just isn't necessary. The two ends of the support are attached to the two rear motor mounts so the thing isn't going to go anywhere. With the bolts removed and the nuts loose you want to pull the bottom of the support towards the rear of the car to give yourself a little more room to get the pump out. If you pull and nothing happens, you may need to adjust the jack to raise or lower the engine slightly; it shouldn't take much force to move the support. Separate the pump from the engine (gently pulling on the pulley should be enough) and make sure that the metal gasket is not stuck to pump. Once it's free from the engine you'll probably have to rotate the water pump a bit to get it out. If it doesn't rotate then part of the gasket is probably stuck to the pump, most likely at one of the two locating pins. It takes a bit of wiggling and the pump will want to get hung up on one of the metal coolant lines, but you should be able to work the pump out past the hoses and rear engine support. I actually removed two of the mounting clips for the metal coolant line on the left side of the engine so I could push the silly thing out of the way a little more.

Not the easiest procedure in the world but far less of a headache than installing the Techquipment roll bar!

  • Upvote 1
  • 3 months later...
kristian Member

kristian

Posted
Posted

Hi,

This was a great DIY. I just had to add that you have to take out the pump from above. Also I got a good deal on a heavy duty pump with metal impeller for $106 on Ebay and it's been working great.

Kristian

  • 1 month later...
ivass Member

ivass

Posted
Posted

I can't open the link to the DIY. Does anybody know if it has been moved, or if it is posted to a different location?

  • Admin
Loren Member

Loren

Posted
  • Author
  • Admin
Posted
I can't open the link to the DIY. Does anybody know if it has been moved, or if it is posted to a different location?

I added a PDF copy to the first post.

  • 4 weeks later...
CabC2 Member

CabC2

Posted
Posted

My pump gave away. Dealer wanted to charge me $1,300. I bought it on sunset, $187 plus shipping, and followed instructions. Spent sunday morning and new pump is installed and working. Thanks Loren and all :)

  • 4 weeks later...
JeTexas Member

JeTexas

Posted
Posted

If you notice, all the water pumps come with a thermostat housing gasket as well. It's not only a good idea to go ahead and replace the thermostat when you do the water pump, but is MUCH easier to slide the pump out if you remove the thermostat housing and can pull that hose out of the way.

By the way, NAPA has started carrying remanufactured 996/986 lifetime warranty water pumps for $144 with an $11 core charge.

  • 3 months later...
  • 2 months later...
JeTexas Member

JeTexas

Posted
Posted

So that NAPA water pump I was so excited about is making grinding noises after only six months. Looks like I'm swapping it again this weekend. I'll try to make a video this time.

If you notice, all the water pumps come with a thermostat housing gasket as well. It's not only a good idea to go ahead and replace the thermostat when you do the water pump, but is MUCH easier to slide the pump out if you remove the thermostat housing and can pull that hose out of the way.

By the way, NAPA has started carrying remanufactured 996/986 lifetime warranty water pumps for $144 with an $11 core charge.

JeTexas Member

JeTexas

Posted
Posted (edited)

Here's the video. Sorry for the shakiness and poor audio. I found my old 24-bit PCI soundcard isn't supported in Windows 7, and I've yet to invest in a new USB recording system.

I only make these when something on my car breaks, so if anyone else in the Houston area wants to collaborate, I'll be happy to assist and film your next project.

Edited by Loren
Fixed YouTube link
  • Upvote 4
  • 4 weeks later...
rlim Member

rlim

Posted
Posted
Here's the video. Sorry for the shakiness and poor audio. I found my old 24-bit PCI soundcard isn't supported in Windows 7, and I've yet to invest in a new USB recording system.

I only make these when something on my car breaks, so if anyone else in the Houston area wants to collaborate, I'll be happy to assist and film your next project.

Excellent DIY video ...Thanks

  • 4 months later...
bgwvdave Member

bgwvdave

Posted
Posted

I wish I would have done this job myself, after watching the video, it looks doable. My problem is my coolant was coming out in a stream the diameter of a pencil and I pulled into my local independent german car shop. For some reason the water pump gasket is connected to the oil pump gasket and I think my awesome mechanic damaged the oil pump housing gasket. The mechanic installed new water pump and now the oil pump housing is leaking coolant, WTF? Has this happened to anybody else? He wants to charge me at least two more hours to fix the leak, **** it is hard to find a good mechanic.

  • 2 months later...
  • 1 month later...
tac27 Member

tac27

Posted
Posted

I recently used this thread to replace the water pump and thermostat on my car; thanks to everyone who posted tips, diagrams, instructions, you-tube videos, and parts pricing.

Now on to the next project, replacing the 'crankcase breather hose' part # 996-107-147 (or 155)-55; anyone have any experience replacing it?

Tim

Las Vegas

'03 996 C2 cabriolet w/manual gearbox.

  • 4 months later...
  • Admin
Loren Member

Loren

Posted
  • Author
  • Admin
Posted

Does anyone have a list of the torque specs for all the differant bolts in this job?

Drain plug - 7.5 ftlb. (with new sealing ring)

Water pump - 7.5 ftlb.

Engine carrier - 22 ftlb.

valley996 Member

valley996

Posted
Posted

It shows $269.99. A little off from $135, now. High price!

After reading that great DIY, I'm inspired to try this. I found an aftermarket water pump on Automotion for only $135:

http://www.automotio...93&dept_id=4329

Anyone have any experience with this unit? I like to save money as much as the next guy, but I'd rather not have to replace this thing again in six months.

  • Admin
Loren Member

Loren

Posted
  • Author
  • Admin
Posted

996.106.011.54 is the latest part number -- US MSRP $295.39

Give the folks at Sunset Imports (Porsche Parts at Dealer Cost) a call or email - you will be pleasantly surprised.
